1. This product can copy IC models PT2260, PT2262, PT2264, PT1527, PT527, PT1587, PT1827, HS2260, HS2262, HS2264, HS2240, HS1527, HS527, HS1587, HS1827, RT2260, RT2262, RT2264, RT2240, RT1527, SC527 , SC1587, SC1827, SC2260, SC2262, SC2264, SC2240, SC1527, SC527, SC1587, SC1827, EV2262, EV2264, EV2240, EV1527.
2. There is no need to consider the oscillation resistance, this product will automatically be compatible with the oscillation resistance.
3. Working frequency: 315MHz
4. Working voltage: 6V
5. Working current: less than or equal to 12mA
6. Copy type: fixed code (2260, 2262, etc.) learning code (1527/2240, etc.) part of the rolling code, etc.
7. Remote control distance: 50-150m (in an open environment, the sensitivity of the receiving device is -100dbm)
8. Modulation method: ASK amplitude modulation
9. Matching method: copy type
10. Application field: suitable for remote control matching and copying of electric door remote control, retractable door remote control, garage door remote control, motor control remote control, curtain control remote control, LED light remote control, automobile and motorcycle remote control, industrial equipment remote control, etc.
Specification:
| Package Weight |
| One Package Weight |
0.04kgs / 0.08lb |
| One Package Size |
10cm * 4cm * 2cm / 3.94inch * 1.57inch * 0.79inch |
| Carton Weight |
13.50kgs / 29.76lb |
| Carton Size |
38cm * 32cm * 28cm / 14.96inch * 12.6inch * 11.02inch |
| Loading Container |
20GP: 783 cartons * 400 pcs = 313200 pcs
40HQ: 1818 cartons * 400 pcs = 727200 pcs
|
|
