1. Use high power magnetic surround inductor and high current control chip, small size, high power, high efficiency 2. Application areas: DIY mobile power, car power supply, communication equipment power supply, etc. 3. Module nature: non-isolated buck 4. Rectification mode: non-synchronous rectification 5. Input voltage: 5V-32V 6. Output voltage: 0.8V-24V 7. Conversion efficiency: up to 90 8. Switching frequency: 300KHz 9. Output ripple: 30mV (no load) 10. Load regulation rate: about 0.5% 11. Voltage regulation rate: about 2.5% 12. Operating temperature: -40 - 85 degrees Celsius 13. External Dimensions: Approx. 4.3 x 2.1 x 1.4cm
