E325 LED Sensor Car Rear View Camera, Support Color Lens / 120 Degree Viewable / Waterproof & Night Sensor Function, Diameter: 28mm, E325

E325 LED Sensor Car Rear View Camera, Support Color Lens / 120 Degree Viewable / Waterproof & Night Sensor Function, Diameter: 28mm, E325

$9.99 USD
$9.99 USD
Sale Sold out
Shipping calculated at checkout.
Option
Features
1. CMOS image sensors
2. PAL/NTSC format
3. Pixel: 628*582, 510*492
4. The TV line: 420, 380
5. The angle of 92/120 degree
6. Work voltage: DC 12V
7. Horizontal resolution: 420 TV lines
8. Scanning system: 2:1 interlace
9. Gamma factor: 0.45


Specification:
General
Model E325
Types Rear View Camera
Display Resolution 656 x 492 pixels
Video Output 1.0 VP-P, 75 ohm
TV System NTSC
Operating Language English, Simplified Chinese, Traditional Chinese
Voltage DC 12V
Waterproof Level IP67, IP68
Camera
Imaging Device OV7950
Lens Angle 135 Degrees
White Balance Auto
Mini Lumination 0.1 lux (IR ON)
Shutter Speed 1/60-1/20000s
Sensing Area 4.08 mm x 3.12 mm
Environment
Working Temperature -20 - 75 Degree Celsius
Storage Temperature -40 - 85 Degree Celsius
Operating Humidity RH 95 Percent MAX
Storage Humidity RH 95 Percent MAX
Package Weight
One Package Weight 0.19kgs / 0.43lb
One Package Size 13.5cm * 8.3cm * 5cm / 5.31inch * 3.27inch * 1.97inch
Qty per Carton 100
Carton Weight 24.00kgs / 52.91lb
Carton Size 46cm * 41cm * 54cm / 18.11inch * 16.14inch * 21.26inch
Loading Container 20GP: 261 cartons * 100 pcs = 26100 pcs
40HQ: 607 cartons * 100 pcs = 60700 pcs
