1. Model: XY-S220H
2. Item: 2.1 channel Bluetooth-compatible audio amplifier board
3. Power supply: above DC12-38V/10A
4. Bluetooth-compatible version: 5.1
5. Audio channel: 2.1 channel
6. Audio input: Bluetooth-compatible+AUX+U disk+USB sound card
7. Audio output: left and right channels + subwoofer
8. Frequency range: 20HZ--20KHZ
9. Volume adjustment: high-end encoder knob adjustment, smooth feel
10. Left and right channel maximum output power: 160W/4ohms----36V DC, 80W/8ohms---36V DC
11. Subwoofer maximum output power: 220W/3ohms----36V DC, 160W/4ohms----36V DC
12. Protection mechanism: overvoltage, undervoltage, clipping, short circuit, overheating, etc.
13. Unique function: Support Sinilink-APP to modify the Bluetooth-compatible name, set the 14. Bluetooth-compatible password, turn off/on the prompt tone
Specification:
| Package Weight |
| One Package Weight |
0.41kgs / 0.90lb |
| One Package Size |
15cm * 12cm * 4cm / 5.91inch * 4.72inch * 1.57inch |
| Carton Weight |
17.00kgs / 37.48lb |
| Carton Size |
42cm * 25cm * 32cm / 16.54inch * 9.84inch * 12.6inch |
| Loading Container |
20GP: 793 cartons * 40 pcs = 31720 pcs
40HQ: 1842 cartons * 40 pcs = 73680 pcs
|
|
